Art-Lynx OP

Dual Art-Net to DMX512/RDM

Art-Lynx™ O/P is a DIN Rail Ethernet to DMX512 converter. It converts two universes of Art-Net Ethernet into DMX512.

Art-Lynx O/P is housed in a small, robust DIN Rail case. The Ethernet connection is made via an RJ45 and the DMX512 connections by removable screw terminal connectors.

The power input can be either from the Ethernet cable using the IEEE 802.3 standard, or from an external power supply. Configuration is simplicity itself. The three rotary dials are used to select the required DMX512 universe.

The product fully supports the ESTA RDM standard.

Art-Lynx O/P can be software upgraded via the network connection.

Features
DMX routing by Ethernet
Connect up to 256 DMX Universes to one network
Two DMX512 outputs
10/100BaseT Ethernet Port
Compatible with DMX512-A
RDM V1.0 (E1.20 - 2006 ESTA Standard)
Power indicator
Data activity indicators
Art-Net Compatible
DIN Rail mounting

Specifications
Listing: CE FCC
IP Rating: Indoor use
Power: 8W
Input Voltage: 9-48VDC
Width: 106 mm
Height: 110 mm
Depth: 62 mm
Connection: RJ45 and removable screw terminal
Ethernet Isolation: Isolated
DMX Isolation: Ground Referenced

Shipping
Net Mass: 0.22 kg
Approximate Carton Mass: 0.36 kg
Approximate Carton Dimensions: 220 x 180 x 110 mm
Volume: 4356000 mm³
Manufacturer: Artistic Licence Engineering Ltd
Country of Manufacture: The United Kingdom
