24CH DMX CV LED Dimmer 5-24V DC 24CH x 3A, max 1728W
LT-880 with the standard RDM remote device management protocol, supports DMX512 signal bi-directional communication, achieves remote management of reading and writing DMX address (DMX master controller must recognize the RDM protocol). This compact decoder works with DMX512 console. Realize 0-100% brightness and various changing effect. Equiped with DMX standard 3-pin XLR,RJ45andgreenterminalinterface,easytooperate.Anditcancontrol single color, bi-color, RGB LED lights
Input signal DMX512
Input voltage DC5V～DC24V
Max load current 3A ×24CH Max 72A
Max output power 360W/864W/1728W(5V/12V/24V)
DMX512 socket RJ45 XLR-3 Green terminal (with signal amplification function)
Dimming range 0~100%
Working temperature -30℃～65℃
Dimension L260×W123×H42mm
Package Size L268×W127×H44mm
Weight (G.W) 885g
