Dimmer, Chilli 24-10i 1212
The installation market demands versatile applications, reliability, and easy installation. Our convection-cooled Chilli installation dimmers have been developed precisely for these constantly changing requirements. Various power options and a user-friendly design offer flexibility for almost every application. With the Chilli series, planning and installation effort is reduced to a minimum. Compatibility with the ChilliNet lighting control system, which uses external wall control units or touchscreens to control scenic lighting, opens up entirely new areas of application. The Chilli series is ideal for installations in multi-purpose halls, shops, hospitality venues, hotels, museums, or professional theater stages.
• 12 phase-control dimmer circuits
• 12 fixed-current relay circuits (non-dim)
• 10A per circuit
• 100% full-load capability
• Circuit breaker with zero-break function (1P+N, Type C)
• Clear menu navigation
• 4 dimmer curves per circuit
• Level limit per circuit
• DMX address per circuit
• Lamp preheating per circuit
• Channel test function
• Automatic frequency adjustment from 45-70Hz
• Control via DMX 512 and ChilliNet
• RDM support
• CAN bus interface via terminal block
• Alarm circuit interface
(e.g., for fire alarm systems)
• DMX termination resistor, internally switchable
• DMX interface via terminal block
• Convection cooling, without fan systems
• Versions with two 4-pole, 30mA RCDs available
• Main switch
• Designed for Optional retrofit relay kits
• Lockable front cover
• Pre-cut cable guides
• CE compliant
• ISO9001:2015 certified
